Threaded terminal with internal thread | Right-hand thread | For cable from Ø 3 mm to Ø 8 mm | V2A
Product information "Threaded terminal with internal thread | Right-hand thread | For cable from Ø 3 mm to Ø 8 mm | V2A"
[ Technical details ] Manufactured from stainless
steel 1.4301/V2A/AISI 304[ Specific details ] Suitable for cable with a diameter of 3 mm to 8 mm; for self-crimping; threads from M5 to M8
[ Application ] Insert the cable into the terminal and crimp using a suitable tool
[ Further specific details ]
Dimensions of threaded terminal for 3 mm diameter rope: A: M5; B: 70 mm; C: 21 mm; D: 6 mm; E: 35 mm
Dimensions of threaded terminal for 4 mm diameter rope: A: M6; B: 70 mm; C: 25 mm; D: 7 mm; E: 35 mm
Dimensions of threaded terminal for Ø 5 mm rope: A: M6; B: 70 mm; C: 20 mm; D: 8 mm; E: 35 mm
Dimensions of threaded terminal for Ø 6 mm rope: A: M6; B: 70 mm; C: 25 mm; D: 9 mm; E: 35 mm
Dimensions of threaded terminal for Ø 8 mm rope: A: M8; B: 110 mm; C: 40 mm; D: 11 mm; E: 50 mm
| Form: | Gewindeterminal |
|---|
Zubehör
Available, : 1-3 days
