Pipe connector | Round wall bracket | 131 | 21.3 mm – 60.3 mm | 1/2" – 2" | Hot-dip galvanised and electro-galvanised

Rohraußendurchmesser: Ø 21,3 mm

FeNau GmbH

£2.93*

Prices include VAT, plus delivery charges

Available: 1-3 days

Rohraußendurchmesser

Ø 21,3 mm

Ø 26,9 mm

Ø 33,7 mm

Ø 42,4 mm

Ø 48,3 mm

Ø 60,3 mm

Stk

Stock: 495

Product number: 131T21

EAN: 4251412901966

Weight: 0.2 kg

20,000 items in stock

CAD data available after login

Over 200,000 satisfied customers

Worldwide delivery

Product information "Pipe connector | Round wall bracket | 131 | 21.3 mm – 60.3 mm | 1/2" – 2" | Hot-dip galvanised and electro-galvanised"

[ Scope of delivery ] 1x floor flange (round / rigid) incl. stainless steel clamping and cutting screws - (Item no.: 131A27) | Optimal corrosion protection against weathering – durable, stable and universally applicable (outer diameter in accordance with DIN EN ISO 6708 and EN 10255)

[ Technical details ] Dimensions (see illustration): For Ø 26.9 mm / ¾" Dimension (A): 42 mm / Dimension (B): 83 mm / Dimension (C): 57 mm / Weight: 0.29 kg | Professional quality thanks to electroplating and hot-dip galvanising - Material: malleable cast iron

[ Wrong size? – Suitable items ] (Item no.: 131T21) Dimensions: Ø 21.3 mm / ½" | (Item No.: 131A27) Dimensions: Ø 26.9 mm / ¾" | (Item No.: 131B34) Dimensions: Ø 33.7 mm / 1" | (Item No.: 131C42) Dimensions: Ø 42.4 mm / 1 ¼" | (Item No.: 131D48) Dimensions: Ø 48.3 mm / 1 ½" | (Item No.: 131E60) Dimensions: Ø 60.3 mm / 2"

[ Application ] Wide range of applications | Fixing for floors and walls – structural fixings for safety/fall protection railings (Item No.: cfg-132) | For steel structures, scaffolding, handrails, railings, shelving, etc. | Not the right pipe connector? No problem, we stock a wide range of pipe connectors in various shapes

For pipe Dimension a Dimension b Dimension c Bore Insertion depth Allen 21.3 mm 32 mm 74 mm 56 mm 8 mm 27 mm301T 26.9 mm 42 mm 83 mm 57 mm 8 mm 39 mm301AB 33.7 mm 48 mm 89 mm 65 mm 8 mm 42 mm301AB 42.4 mm 50 mm 102 mm 76 mm 8 mm 46 mm301CDE 48.3 mm 59 mm 114 mm 89 mm 8 mm 52 mm301CDE 60.3 mm 64 mm 127 mm 95 mm 7 mm 58 mm301CDE

Versand Gurtmasspflichtig:	Nein
Ø Für Rohr \| Ø Außendurchmesser \| Ø Anschluss:	Ø 21.3mm (1⁄2″)

Zubehör

301T21

Pipe coupler | Hex key | for S17 & T21 / A27 / B34 & C42 / D48 / E60 | Stainless steel

Pipe connector | Hex key | for T21 & A27 / B34 & C42 / D48 / E60 | Stainless steel

Available, : 1-3 days

£1.57*

133T21

Pipe connector | Light grey plastic plug | 133 | 21.3 mm – 60.3 mm | 1/2"–2"

Pipe connector | Light grey plastic plug | 133 | 21.3 mm – 60.3 mm | 1/2"–2" | Malleable cast iron and electro-galvanised [ Specific details ] for pipe Ø: 21.3 mm – 60.3 mm (1/2"–2"); wall thickness: 2–4 mm [ Application ] Insert plastic plugs into open pipe ends to seal

Available, : 1-3 days

£0.22*

133T21-S

Pipe connector | Black plastic plug | 133-S | 21.3 mm – 60.3 mm | 1/2"–2"

Pipe connector | Black plastic plug | 133 | 21.3 mm – 60.3 mm | 1/2"–2" | Malleable cast iron and electro-galvanised [ Specific details ] for pipe Ø: 21.3 mm – 60.3 mm (1/2"–2"); wall thickness: 2–4 mm [ Application ] Insert plastic plugs into open pipe ends to seal

Available, : 1-3 days

£0.22*

30.2221-500.7

Balustrade tube | Ø 21.3 x 1.75 mm | Length: 500 mm / 1000 mm / 1500 mm | S235JR steel, galvanised

Balustrade tube | Ø 21.3 x 1.75 mm | Length: 500 mm / 1000 mm / 1500 mm | S235JR steel, galvanised We are happy to produce tube cuts to your specified lengths! [ Technical details ] S235JR steel, galvanised [ Specific details ] Length: 6000 mm; Tube Ø 21.3 x 1.75 mmLength: 6000 mm; Tube Ø 21.3 x 1.75 mm [ Further specific details ] Tube in accordance with EN 10219 / EN 10240

£11.90*

30.2221-1000.7

Balustrade tube | Ø 21.3 x 1.75 mm | Length: 500 mm / 1000 mm / 1500 mm | S235JR steel, galvanised

Balustrade tube | Ø 21.3 x 1.75 mm | Length: 500 mm / 1000 mm / 1500 mm | S235JR steel, galvanised We are happy to produce tube cuts to your specified lengths! [ Technical details ] S235JR steel, galvanised [ Specific details ] Length: 6000 mm; Tube Ø 21.3 x 1.75 mmLength: 6000 mm; Tube Ø 21.3 x 1.75 mm [ Further specific details ] Tube in accordance with EN 10219 / EN 10240

Variants from £11.90*

£23.81*

30.2221-1500.7

Balustrade tube | Ø 21.3 x 1.75 mm | Length: 500 mm / 1000 mm / 1500 mm | S235JR steel, galvanised

Balustrade tube | Ø 21.3 x 1.75 mm | Length: 500 mm / 1000 mm / 1500 mm | S235JR steel, galvanised We are happy to produce tube cuts to your specified lengths! [ Technical details ] S235JR steel, galvanised [ Specific details ] Length: 6000 mm; Tube Ø 21.3 x 1.75 mmLength: 6000 mm; Tube Ø 21.3 x 1.75 mm [ Further specific details ] Tube in accordance with EN 10219 / EN 10240

Variants from £11.90*

£27.41*

Gelaenderrohr - Ø 21-3x1-75 mm - Laenge- 6000 mm - Stahl S235JR- verzinkt-30-2221.7

Stk

30.2221.7

Balustrade tube | Ø 21.3 x 1.75 mm | Length: 6000 mm | S235JR steel, galvanised

Balustrade tube | Ø 21.3 x 1.75 mm | Length: 6000 mm | S235JR steel, galvanised We are happy to produce tube cuts to your specified length! [ Technical details ] S235JR steel, galvanised [ Specific details ] Length: 6000 mm; Tube Ø 21.3 x 1.75 mmLength: 6000 mm; Tube Ø 21.3 x 1.75 mm [ Further specific details ] Tube in accordance with EN 10219 / EN 10240

Available, : Lieferzeit 3-5 Werktage

£44.60*
